Rosenbauer PANTHER

Series: PANTHER
Engine: Volvo Penta D16, Euro 6
Engine power: 551 kW (750 HP)
Transmission: automatic Twin Disc 8-speed
Water tank: 12500 liters
Foam tank: 1500 liters
Dry chemical powder: 250 kg
Pump system: Rosenbauer N80
Extinguishing capacity: 8000 l/min at 10 bar
High pressure pump system: Rosenbauer H5
High pressure extinguishing capacity: 500 l/min at 40 bar
Foam proportioning system: FIXMIX 2.0 A
Front turret: RM35 HVLA
HRET: STINGER 54
HRET turret: RM65
HRET maximum working height: 16,5 m
HRET maximum outreach: 11,4 m
Vehicle dimensions: 11710 × 3000 × 3650 mm
Permissible maximum weight: 39000 kg
Wheelbase: 4800 mm
